Compact Power, Maximum Maneuverability
The UniCarriers TX-M Series 3-wheel electric forklifts are engineered for precision handling in tight spaces. With capacities ranging from 3,000 to 4,000 lbs, these forklifts deliver exceptional performance in confined environments.
Key Features
-
Advanced AC Technology: 100% AC-powered system with brushless drive and pump motors ensures efficient, emission-free operation.
-
Electric Power Steering: Provides precise control with reduced energy consumption, enhancing operator comfort.
-
Extended Service Intervals: Major maintenance intervals set at 1,000 and 2,000 hours, reducing downtime and maintenance costs.
-
Operator Comfort: Full-suspension seat with weight and back angle adjustments, hip restraints, and retractable seatbelt for a comfortable ride.
-
Sealed Components: IP54-rated sealed motors and controllers protect against debris and moisture, ensuring reliable performance in various conditions.
Model Variants
-
TX30M
-
Load Capacity: 3,000 lbs
-
Power: 36V / 48V
-
Turning Radius: 58.1 in
-
Overall Length: 72.8 in
-
Chassis Width: 42.9 in
-
Load Capacity: 3,500 lbs
-
Power: 36V / 48V
-
Turning Radius: 62.4 in
-
Overall Length: 77.1 in
-
Chassis Width: 42.9 in
-
-
TX40M
-
Load Capacity: 4,000 lbs
-
Power: 36V / 48V
-
Turning Radius: 62.8 in
-
Overall Length: 78.1 in
-
Chassis Width: 42.9 in
-
Options and Accessories
-
Battery Options: 36V or 48V configurations to suit various operational needs.
-
Onboard Diagnostics: Self-contained system for easy troubleshooting and maintenance.
-
Ergonomic Enhancements: Adjustable seating and non-cinching seatbelts for operator comfort.
-
Safety Features: Controlled rollback and advanced stability systems for secure operation.
-
Maintenance Accessibility: Gas stay assist for easy hood opening and battery access.
