ugged Performance for Demanding Environments
The UniCarriers RPX Series walkie end rider pallet trucks are engineered to deliver consistent performance across various challenging environments. With load capacities ranging from 6,000 to 8,000 lbs, these 24V AC-powered trucks are designed for applications requiring adaptability and durability, from cold storage facilities down to -20°F (-28.9°C) to dry ambient warehouses.
Key Features
-
Sealed Systems for Harsh Conditions: Equipped with sealed switches, an epoxy-coated control board, IP65-rated sealed controller, and sealed steer race, the RPX Series ensures reliable operation in wet, cold, and dry environments.
-
Powerful AC Drive Motor: The 5.2 HP brushless AC drive motor offers greater torque and faster travel speeds, enhancing productivity while using less energy per cycle.
-
Ergonomic Design: Features a spacious operator platform with a rubber-padded, intermediate high-speed handrail and large, soft-touch control buttons for improved comfort and control.
-
Smart Electric Brake System: Utilizes regenerative motor torque before brake actuation, reducing component wear and extending service life.
-
Onboard Diagnostics: Integrated diagnostics system provides real-time feedback, simplifying maintenance and minimizing downtime.
Model Variants
-
RPX60B
-
Load Capacity: 6,000 lbs
-
Power: 24V AC
-
Chassis Width: 35.6 in
-
Chassis Height: 42.7 in
-
Maximum Fork Height: 9.25 in
-
-
RPX80B
-
Load Capacity: 8,000 lbs
-
Power: 24V AC
-
Chassis Width: 35.6 in
-
Chassis Height: 35.6 in
-
Maximum Fork Height: 9.25 in
-
Options and Accessories
-
Lithium-Ion Battery Options: Maintenance-free batteries with a life expectancy of up to 5,000 full cycles, reducing total cost of ownership and downtime.
-
Coast Control with Sidetracker: Enhances order picking efficiency by allowing the operator to walk alongside the truck.
-
Multi-Function LCD Display: Provides access to customized performance settings, displays battery discharge indicator, and offers onboard diagnostics and troubleshooting.
-
Stainless Steel Axles and Linkage Pins: Enhances durability and corrosion resistance in harsh environments.
Warranty
UniCarriers backs the RPX Series with a comprehensive warranty, reflecting their commitment to durability and customer satisfaction.
